Oil Fired Boiler Modulating System

1 Piece (MOQ)

Business Type Manufacturer, Supplier, Trader
Voltage AC 230V, 50Hz Single Phase
Drive AC Servomotor with electromagnetic brake.
Power Input 50 Watts
Click to view more

Preferred Buyer From

Location Anywhere in India

Product Details

Load on End Shafts
300 Kg-cm
Torque on end Shafts
29.43 Nm
Running Time
30 Sec
180 Degrees
Complete Shut Off of Air Damper
Additional running time of 15 sec, Additional rotary motion 90 Degree
Feedback Potentiometer
135 Ohms, 0.3Watt 270 Degree Operating Range

Panchal Modulating Unit is a fully mechanical geared unit which is designed to control the burner output (Size of the Flame) to match the Boiler variable and load requirements. Our units help the burner to stay at the correct fuel to air ratio across the complete firing range to ensure the maximum combustion & boiler efficiency. Panchal’s Modulating unit controls the nonlinear relationship between the fuel and the air ratios. It is used to control Air Damper with the help of linkages and also to control the volume flow rate of the gas with the help of butterfly and its linkages in case of Gas Burners.
